Carbon fiber bicycle assembly method Introduction
2016-06-14
First on a finished map, because of their independent production process so wrapped carbon cloth was not recorded, please forgive me
Line drawings, drawings can not find the handle, I would like him to forgive the above drawing is based on its own data and then fitting to reference other bike looks conducted the final shape
First we honed in accordance with the drawings tell the handlebars, attention here is spliced in many places, because I was so polished scrap block more.
My first step is to parcel wrapped with 3k amorphous carbon cloth for the handlebar, such as dry again after the package 12k
This is a handlebar fixtures, floor 3k, 12k bi-layer, layer 1 Kaila Fu, one 12k Kaila Fu layer, a layer of 12k
This device is used to secure the handlebars and the connecting means established
This is a side view of the device, to ensure that the angle of 72.5 Oh, think of ways
The handlebar 10 with a hole punch to hit the air, but not quite in the middle,
Look at this structure, it is necessary handlebar flat on your device, and ensure that the angle of 72.5 degrees, and then use the cloth to wrap 12k bi-layer shape, and then in the other package
Some people ask how many layers wrapped handlebar, in fact I do not remember, I mainly want to complete bald career, you get a random handshake places that are rough, but fortunately I Do, do their own Kazi was a rival variable variable installation to get started.
The next step is the fork, because there is no buy fork piece
So do yourself a pair, specifically the number of layers pressed to forget, in short, 12k bi medicinal 12 floors above, I was all on the line with a neutral stone compacted, very very strong
Grinding machine with the cornea.
Because relatively small fork, so I used wood polished, there is no sponge, the sponge during winding deformation occurs.
My first concrete step is a fork wrapped electrical tape and then covered with a layer 3k carbon cloth, and so did later cut open with a knife from the middle, out of the wood model. 12k carbon cloth and then use it for individual rebate covered stereotypes.
Must pay attention to the following location, pitch fork arm and the wheels must be large enough, or else spread layers of carbon cloth, since there is no gap, and for this I made two fork.
I bought a cushion when the production model, wrapped
Now the surface layer of electrical tape
This is the first step in a good brush resin, carbon cloth hardens until the time fixed by hand shape
This cushion I mainly Bullock 3 layers 12k bi-cloth, a layer Kaila Fu
As for the joints and cushions the seat tube, carbon cloth can not be directly around the corner, so do a buffered model form radian connection
The above connection I use the car fixed up soil in this way I feel very very strong.
Stuff underneath for compacting carbon cloth I use a sanding sponge general shape, wrapped with tape, and then compacted wound
Local connection with a two-layer 12k layer Kaila Fu. Now I feel the quality of Leveragediy fun that was never able to buy their own hands, so decided to get their own head pipe Bicycle theme, I did not do it with models, distribution structures, and docking.
Source:tieba
Author:Fengkuangpizhiwang
